    50HZ 0.8MPA Pressure Decay Leak Tester IP Test For Electric Toothbrush 150kPa

    Ask Lasest Price
    Brand Name : Seals-ins
    Model Number : YLA-M-XXXX-D
    Price : $1,000.00 - $10,000.00/Pieces
    MOQ : 1set
    • Product Details
    • Company Profile

    50HZ 0.8MPA Pressure Decay Leak Tester IP Test For Electric Toothbrush 150kPa

    Pressure Decay Leak Tester IP Test Machine for Electric Toothbrush

    Product Paramenters
    Item
    Testing Machine
    Test medium
    Compressed air or specified medium by customers
    Gas source
    0.4-0.8MPA (clean, dry)
    Power supply
    AC220V(±15%),50HZ,ground lead
    Environmental temperature
    0-50℃
    Environmental humidity
    ≤95% (not dew)
    Pressure adjustment range
    -20kPa~150kPa
    Number of test ports
    1
    Status of the tested product
    With or without hole, semi finished or finished product
    Pressure mode
    Positive and negative pressure
    Pressure adjustment precision
    0.05%F.S
    Measurement range of the senor
    -20kPa~150kPa
    Measurement range precision of the senor
    0.02%FS
    Pressure minimum setting unit
    1Pa
    Resolution ratio
    1Pa
    Dimension
    335*305*285
    Gross weight
    11KG
    The SLA direct pressure leak detector is mainly used for test of the semi-automatic or fully automatic leak with the dry compressed air as a medium, inflating the tested parts with the possitive pressure(or negative pressure), and determines whether the filled gas has leak. When verifying, the compressed air source is cutting off, if the air within the tested products leaks, the test pressure will inevitably change. What we need to test is this variation in pressure. By calculation of the
    pressure change of the tested object, we achieve the good or bad judgment of the tested products on the production line.
    uses air as the medium to detect leaks. It is a non-destructive testing instrument. The working principle is to inflate the test article to the specified air pressure, then close the valve. After a period of stability, measure the change of the air pressure during the detection period, and calculate the leakage amount by conversion. This instrument is widely used in the sealing test of open products or sealed products with its high precision and full-featured features.
